standard specifications
Standard
-
Dual Control Stations with Direct Link Activated Levers
-
Pavement Pads with Flipper Feet
-
Hydraulic Pump
-
Independent Hydraulic Rear Spades
-
Pressure Gauges
-
Tailboard D-Rings
-
Tailboard Fork & Tie-Down Chains
-
Safety Chains in Rear Pockets
Boom
-
Power Elevation & Power Extension
-
Dual Planetary Winches
-
Nylon Pads in Boom
-
Winch Air Free Spool
-
Cable Tie Backs
-
Cable Tensioners
-
360° Sheave Heads
-
Winch Air Free Spool
Underlift
-
3-Stage Design
-
Low Profile 70º Pivoting Heavy Duty Fabricated Cross Bar
-
Low Profile Fork Holders
-
9 Sets of Cast Steel Forks: Short Axle Fork, 3” Short, 3” Medium, 3” Tall, 5” Short, 5” Medium, 5” Tall, 6” Short Offset, Round Axle Fork
-
Pivoting Spring Lift Adapters
-
King Pin Tow Plate
-
Chain Hook End Caps
-
Power Tilt - Hydraulic Fold
Body
-
96” Wide Steel Modular Body
-
Rubber Mounting Isolators
-
LED Body Lighting
-
Antiskid Design Walkway
-
LED Tool Compartment Lighting
-
Chrome Double Action Latches with Keyless Lock and Unlock
-
Door Shocks
-
Lift Fork Storage
-
Chain Storage
-
Mud Flaps
Options and ad ons
-
Air Shift PTO
-
Wireless Remote Control
-
Hour Meter
-
Quick Connect Air Supply & Electric Hook Ups
-
Light Pylon
-
Euro Stinger - 144”
-
22,000 lbs. Under Boom Auxillary Winch
-
Multi-Positional Flipper Feet
-
Rear Outrigger - Horizontal
-
Spreader Bars
-
Dual Rear Camera & Monitor
-
Tailboard Underlift Controls
-
Convenience Groups
-
Aluminum Dress-Up Kits
-
Installation
-
Underlift Light Kit (LED)
-
Heavy Duty Tire Lift
-
Tire Lift Storage Brackets
-
Snatch Blocks
-
Water Tank Kit
-
Additional Lighting
-
Side Work lights
-
Additional Lift Forks
-
Screw Pin Shackle Kit
-
Endless Loop Sling Package
-
Chain Package
-
Fork Risers
-
Pintle Hook Attachment
-
5th Wheel Plate
-
King Pin Attachment
-
Trailer Ball Adapter
-
Wide Load Light Bar
-
Adjustable Shelves
50 ton wrecker chassis remendation
Boom
Retracted 30°
Extended 30°
Maximum Angle
Maximum Hook Height
Hydraulic Boom Extension
100,000 lbs.
18,000 lbs.
35°
304"
216"
Winch
Feature
Winch Capacity
Winch Type
Cable Specifications
Cable Type
Main Winch
50,000 lbs.
Dual Planetary Winch
3/4" x 250' I.W.R.C.
6X37 I.W.R.C
Auxiliary 3rd Winch
22,000 lbs.
Planetary Winch
5/8" x 150' I.W.R.C.
I.W.R.C
Underlift
Feature
Fully Extended to C.L. of Forks
Fully Retracted to C.L. of Forks
Underlift Tilt
Tow Rating
Standard
18,000 lbs. @ 116”
55,000 lbs. @ 60”
18°
80,000 lbs.
Euro-Stinger
18,000 lbs. @ 144”
55,000 lbs. @ 67”
18°
80,000 lbs.
Body
Feature
Common Body Configuration
Additional Body Configuration 1
Tandem Axle
160” C.B.
180” / 200 ” / 220” C.B.
Tri Axle
180” C.B.
200” / 220 ” C.B.
Chassis Recommendation
Front Axle
Rear Axle
Clear C.A. / C.B.
After Frame from Center of Rear Axle
RBM
14,600 lbs.
40,000 lbs.
156” – 220” C.A.
36”
3,000,000 in/lbs.
